Sunday, July 20, 2014

Photography Tripod



A tripod is an essential part of a photographer’s equipment list. Its primary function is to provide, solid, stable support to the camera, allowing the photographer to shoot with a much slower shutter speed than would normally be possible if the camera was handheld.




Travel Tripod
A Guide to Tripods for Travel Photography

The reasons you might need to use a slow shutter speed include:

    Low Light – When the light is insufficient to provide a suitably high enough shutter speed.

    Depth of Field - When a photographer is using a deep depth of field i.e. a small aperture the shutter speed will subsequently be much lower.

    Macro – When shooting subjects up close it is necessary to stabilize the camera to minimize camera shake.

Tripods are not ideally suited to traveling photographers, they often add substantial weight to luggage and are cumbersome and awkward to both carry and use. There are, however tripods that have been specifically designed for travel photographers combining both lightness and rigidity allowing the photographer the freedom to travel and carry his tripod for extended periods.

Good quality travel tripods are generally sold in two separate parts, the legs and the head. Both of these parts can be further broken down into specific areas that should be considered carefully when purchasing a camera tripod. Lets take a more in depth look at what to look for in a travel tripod.


A good quality tripod will be sold as two separate parts, the legs and the head
Tripod Legs

The tripod legs are the first part of the equation. Depending on their cost they can be made of various materials. A travel photographer will be looking for three things, low weight, rigidity and the flexibility to move the legs into awkward positions and angles.

Plastic – The only redeeming features of plastic tripod legs are their price and that they will be light. They will however not be anywhere stable enough for a serious travel photographer and will be prone to breaking easily.

Aluminum – This is the standard material for entry level serious tripods. It is immensely strong and rigid however can be quite heavy, an important consideration if using a tripod for travel.

Carbon Fiber – The new generation of carbon fiber tripod legs are probably the best option for a travel photographer, they combine remarkable lightness with excellent strength. They are however significantly more expensive than the equivalent aluminum legs.




A set of Manfrotto Carbon Fiber Legs, ideal for travel

The next consideration is the number of leg sections and the leg locks. Most tripod legs will be three or four sections. Three-section tripod legs have the advantage of greater rigidity whilst a four-section tripod will often be more compact, an important consideration when traveling.

Leg locks fall into two categories, twist locks and lever locks. What you choose here is purely personal preference.


Next you need to look at two further aspects the maximum height of the tripod and center column and the maximum load. For a good travel tripod you need to look for a set of legs that will bring the center column up to a little below eye level allowing the camera to be at eye level once mounted on the tripod head. For the maximum load weight consider the weight of your camera with the largest lens that you own. For most travel photographers a good aluminum or carbon fiber tripod should exceed your equipment weight unless you are shooting medium format.





Lets look at some typical specifications for a good tripod legs.

    Weight (without head): 2 to 4 lbs (0.9 to 1.8 kgs)
    Height (contracted): 12 to 20 inches (30 to 50cm)
    Height (extended): 60 to 70 inches (152 to 178cm)
    Max Load: 5 to 10 lbs (2.3 to 4.6 kgs)

Typical prices for a good quality travel tripod would be:

    Aluminum: $150-300 (without head)
    Carbon Fiber: $250-500 (without head)




Tripods-Choosing and buying camera support
for video and photography




As we mentioned, the legs are the first part of the equation, the second part is the tripod head. A travel photographer is looking for a head that will again be lightweight, give good fluid movement over a large range of angles and provide a solid lock to the camera. Lets look in detail at head options for travel photographers.


Tripod Head

The head component of a travel tripod should be as well researched as the legs. Again, as with many things, you get what you pay for and when budgeting for a tripod make sure to allocate 25-30% of the budget to a head. Lets have a look at the options available.




Ball and Socket – This is perhaps the simplest and possibly the most suitable head for travel photography. As it’s name suggests, the camera plate is attached to a ball, which in turn sits inside a lockable socket. This gives a huge range of potential movement and allows the camera to be positioned very quickly. Make sure that if purchasing a ball and socket head you check it’s maximum loading, if your camera is too heavy for the head you run the risk of the lock slipping. Prices for ball and socket heads suitable for travel range from $50-$150





Pan and Tilt – These heads allow you to move the camera in three planes using separate controls, horizontally, vertically and also the orientation of the camera from landscape to portrait. You can lock off one plane whilst moving the camera in another. These heads tends to be a bit bigger and hence more heavy than a ball and socket type but often can sustain higher loads and give more accurate control. The price for a good quality head will be $75-$200



When buying a head there are some features that you should look for that can make life easier for a travel photographer. Firstly is a quick release plate. This allows you to quickly mount and remove the camera from the tripod allowing you more freedom in your shots. If you shoot with two cameras you can use a plate on each.

Secondly a built in spirit level is also an extremely useful aid, especially for photographing landscapes and architecture on trips. It allows you to confirm that the camera is level in both the horizontal and vertical plane.









Suggested Manufacturers

Although not an exclusive list the following are some of the best regarded tripod manufacturers. All have tripods in their ranges that are suitable for travel photographers.

Manfrotto – Produce good quality tripods for reasonable prices. They have a wide range of carbon fibrer legs as well as a huge selection of heads.



Gitzo – Many professionals include a Gitzo tripod amongst their kit. They have an excellent reputation for quality but they are not for the budget minded.



Benro – A fairly new kid on the block, they are a Chinese company whose reputation for quality on a budget is increasing.



Really Right Stuff – Another up and coming company, Really Right Stuff tripods are designed and built in the US and have a loyal following amongst professionals.



Slik – This Japanese company has some very cheap level tripods that are not ideal for travel, however their mid to high range tripods and heads are excellent quality.



In summary, when researching the purchase of a travel tripod, the key elements to look for are size and weight, it needs to be small enough to put in an overhead locker and light enough to be considered for hand baggage. It needs to be rigid, and here despite the extra cost, a carbon fiber tripod will truly come into it’s own and you need to have a good quality head, one that again is not too heavy but gives great fluidity as well as stability.


How to Choose and Buy a Tripod for a DSLR Camera

Choosing a tripod can be an overwhelming experience, given how many different types and choices we are presented with. On one hand, a tripod is a very simple tool to keep our cameras steady when we use them in challenging light conditions. On the other hand, there are so many different variables that come into play when choosing a tripod: How tall should it be? How light should it be? How stable should it be? What kind of weight can it support? How much should I spend on a tripod? These are just some of the questions that might come up as you look into buying a new tripod.

Before getting into the intricate details about tripods, I would like to go over the advantages and disadvantages of tripods and why you might need one for your DSLR.


1) Why do you need a tripod?

So, what is the purpose of a tripod? You might need a tripod for some or all of the following reasons:

    To increase sharpness and depth of field in your images by keeping the camera still in low-light environments when using slow shutter speeds.
    To rest heavy camera gear such as long telephoto lenses on the tripod.
    To increase the quality of the images by keeping the camera ISO low.
    To allow more careful composition, while framing the shot exactly how you want it.
    To shoot HDR and panoramic shots that require exactly the same framing and precision.
    To photograph nighttime objects such as the Moon, planets, stars, etc. as well as painting with light or using available light for landscape and architectural photography.
    To do self-portraits with a camera timer.
    To shoot extreme close-ups/macro (flowers, insects, etc).
    To hold various objects such as flashes, reflectors, etc.
    To shoot at difficult or impossible (hand-held) angles.
    To shoot vibration-free videos.
    To defend yourself :)





I personally use a tripod for one main reason – landscape photography. Shooting sunrises and sunsets can be quite challenging, especially when the light conditions are far from ideal. Although with the recent introduction of ultra wide-angle lenses such as Nikon 16-35mm f/4.0 VR with vibration-reduction technology and DSLR cameras such as Nikon D3s that have very impressive high ISO performance, you are almost no longer required to use a tripod. However, I still prefer to use a tripod to keep camera ISO low (at base ISO) and to frame the shot for HDR and panoramic images.

In addition, there are situations where you must use a tripod in order to slow down and blur action, such as photographing streams and waterfalls as shown in the image below. Therefore, if you are into landscape photography, a good tripod is a must and any pro will tell you the same thing.

Occasionally, I might use a tripod for wildlife photography (specifically birds), but not during long hikes, due to inconvenience and weight factors.





2) Tripod components – what is a tripod system?

A tripod system is generally comprised of the following parts:

    Legs – the obvious. Tripod legs are typically made of aluminum, basalt, steel or carbon fiber.
    Head – the part that holds a digital camera or a lens. There are many different types of heads, but the most popular types are ball-heads and pan-tilt heads.
    Centerpost/Center Column – a separate leg that runs through the middle, allowing to further raise the tripod head.
    Feet – good tripods allow changing tripod feet at the end of the legs for indoor and outdoor use.

The cheapest tripods have legs with an integrated non-replaceable head and feet and sometimes have a centerpost, while the top-of-the-line tripods have a modular tripod system that have replaceable feet and allow attaching a separate tripod head (the head is typically not included).


3) Disadvantages of using a tripod

Tripods are nice and can give you many options to get the highest quality image. However, there are also some significant disadvantages of using tripods, specifically:

    They are heavy. Although there are relatively lightweight carbon-fiber tripods out there, once you add a tripod head, the setup becomes quite heavy.
    They are inconvenient. No matter how small and collapsible your tripod is, it still occupies space and is often inconvenient to carry around or travel with.

    They are difficult to use in crowded environments.
    They can be expensive. Good tripod systems can cost over $1,000.
    They can take a while to set up, making you miss the best moment.
    You can easily damage your camera and lens if you do not know how to properly operate a tripod, or if the tripod system is cheap and unstable.




4) Factors to consider when choosing a tripod

You started your tripod shopping spree and have no idea where to start. What factors do you need to consider when purchasing a tripod? As I have pointed out above, purchasing a tripod can be an overwhelming experience, given how many different choices we are presented with from small and compact to large and heavy. Let’s go through each factor and identify your needs:


4.1) Weight Rating

The first thing I would look at is how much weight a tripod can support. Many photographers make a mistake of buying a tripod that can only support a few pounds and is not made for heavy DSLR equipment. What ends up happening is the obvious – at one point or another the whole thing collapses, destroying the DSLR and the lens. Always make sure that the tripod you want to buy can support at least 1.5 times more than the total weight of your camera and your heaviest lens. I say at least, because I prefer to keep it at around 2x more.

Do not forget that you will at times apply pressure on your camera and sometimes even rest your hands on the setup if you are shooting with long lenses, which adds to the weight. You might also add a flash or a battery grip to your camera in the future, so you have to keep all of that in mind.




4.2) Tripod Height

I always recommend buying a tripod that matches your height, so that you do not have to bend to look into the viewfinder. Once you put your camera on a tripod, the viewfinder should be at your eye level. It is OK if it goes higher than your eye level, because you can always adjust the legs to be shorter. However, if it is much below your eye level, you will find yourself bending all the time, which can be a tiring experience, especially when you are waiting for some kind of action and need to constantly look through the viewfinder.

If you are buying a tripod with an attached head, you want the tip of the head to be on your jaw level. If you are buying a modular tripod with a separate head, make sure that the legs end approximately on your shoulder level.

Another factor to consider is tripod height when it is folded for easier travel. Do you need it to fit in your carry-on luggage? Mine barely does diagonally, with feet removed, and I take it with me everywhere I go.




4.3) Tripod Weight and Construction

Weight is a significant factor when choosing a tripod. You do not want your tripod to be too heavy, because you will find yourself leaving it at home, rather than taking it with you on the road. The lightest tripods are made of carbon-fiber material, which is extremely durable, stable and does not rust. While carbon-fiber is the best material for a tripod, it unfortunately comes at a high price tag.

The next best construction material is aluminum, which is heavier than carbon fiber. Most cheaper tripods are made of aluminum today. You can also find tripods made of stainless steel, but those are generally used for video equipment and are too heavy for regular use.

In terms of total weight, try to keep the tripod legs without the head under 5 pounds. Generally, carbon fiber legs are between 3 and 4 pounds, while aluminum legs are between 5 and 6 pounds, depending on the size and how much weight they can support. Basalt lava legs are somewhere in-between both in terms of weight and cost.




4.4) Tripod Legs

Tripod legs generally come in two forms – tubular and non-tubular. All carbon-fiber legs come in tubular form and have a threaded twist-lock system to secure the legs, while aluminum, basalt and steel tripods might come in different shapes with a flip-lock. Depending on the maximum height of the tripod, there might be between 3 and 5 sections on tripod legs. The more sections, the higher the tripod and generally a little less stable.



4.5) Tripod Feet

Some advanced tripods will allow you to replace tripod feet for different conditions and situations – they just unscrew on the bottom of the tripod legs. There are different types of tripod feet for indoors (rubber or plastic) and outdoors use (metal spikes). Unless you are planning to shoot in icy, rainy/slippery conditions, the standard rubber feet that come with your tripod should work just fine.
Gitzo Tripod Feet



4.6) Centerpost

Some tripods come with a centerpost – a single leg in the middle of the tripod that allows you to increase or decrease the height of the camera by simply moving the centerpost in upward or downward direction. Although some photographers find it convenient and nice to have, I strongly advice against having a centerpost on a tripod. A centerpost defeats the whole purpose of a tripod – it is essentially the same thing as having a monopod on top of the tripod. It might not be as pronounced if you are only shooting with a wide-angle lens, but once you set up a long telephoto lens, you will quickly understand that using a centerpost will cause too much vibration. If you still want to get a centerpost for whatever reason, make sure that it can fully decline to the same level as where the tripod legs meet. The centerpost should never wobble at its lowest level.


4.7) Tripod Head

A tripod head is the most essential part of the tripod system. It is responsible for securely holding camera equipment and controlling camera movement. A modular tripod system does not come with a head and you have to buy it separately. When choosing a tripod head, always make sure that it can support at least the same amount of weight your tripod legs can.




There are three types of heads commonly available:

    Pan-Tilt Head – either with a single handle for horizontal movement or dual handles for both horizontal and vertical movement. This is the most common type of head that is typically built into cheaper tripods.

    Ball-Head – compared to pan-tilt heads, ball-heads only have one control that loosens or tightens the grip. They are very flexible and allow very smooth operation while keeping the camera/lens securely tightened.

    Gimbal Head – a specialized head for long and heavy 300mm+ lenses. Compared to pan-tilt heads and ball-heads, gimbal heads perfectly balance the camera and heavy lens and are best suited for fast-action photography. They are extremely easy to use in any direction and do not require tightening the head every time the camera/lens moves.

I started out with a pan-tilt head and eventually switched over to a ball-head with a quick-release system (see next), due to flexibility and easiness of use.




4.8) Quick-Release System

Every modern DSLR comes with a thread on the bottom of the camera that allows you to attach it to a tripod or a monopod (heavy lenses also come with a similar thread on the tripod collar). This threaded system makes it extremely inconvenient to attach cameras and lenses on tripods, because you would have to either rotate the camera or the tripod to attach them together. To make it easier and more convenient for photographers, manufacturers came up with a great solution – to attach a small removable plate on the camera or lens, which then can be tightly secured on the tripod head.


Cheaper tripods come with a simple plastic plate that can be attached on any camera or lens, while some of the more expensive tripod heads come with a more durable plate. The best quick-release system, however, is the Arca-Swiss Quick Release System. It has more or less become a standard among manufacturers and it has proven to be a very effective solution for quick and easy operation. Compared to plastic plates, the Arca-Swiss Quick Release System is made of very strong aluminum and allows attaching the camera/lens on a tripod without the need to rotate anything. A quick-release plate is permanently attached to a camera or lens, which then easily slides into a quick-release clamp (pictured below). The locking mechanism is simple, yet super tight for a vibration-free operation.

The beauty of this system is that some manufacturers like Really Right Stuff and Kirk Enterprises offer not only plates for almost any camera and lens, but also replacement lens tripod collars, flash brackets, L-brackets and other accessories for the Arca-Swiss Quick Release System. The only downside of the Arca-Swiss Quick Release System is that it is not cheap – you also have to purchase separate plates for each camera and lens.





4.9) Stability

A heavy tripod does not always mean that it is stable. There are plenty of tripod systems out there that are heavy and durable, yet lack the much-needed stability when used in various weather conditions. When a tripod is fully set up, it has to withstand not only wind, but also occasional bumps and knocks that might happen in the field. You always need to make sure that your camera and lens balance on a tripod rather than lean towards one direction, because you might end up damaging your equipment if the head is not fully tightened or if the front outweighs the back and everything falls on the ground.



5) Which tripod should you buy?

Now that you are familiar with all the criteria for selecting the right tripod, you are probably wondering which tripod you should buy for your photography needs. Since I have numerously gone through the experience of shopping for tripods and have seen others do the same, let me tell you what many photographers end up doing. They first look for the cheapest tripod available that will be good enough to hold the first DSLR, since they have no idea if they really need it or do not know how often they would be using it. The tripod would cost between $75 and $150 for legs and head, which is a good price for a simple tool. Next, they purchase a longer and heavier lens and add more weight to the setup. All of a sudden, they find that the cheap tripod is not good enough and they need something more durable and stable.


After making the first mistake, they suddenly realize that they need to do more research and they spend countless hours reading about tripods on different websites and forums. Despite all recommendations from the pros, they are not willing to invest on a top-of-the-line tripod with a good ball-head, so they end up getting a popular tripod system for $300-500 with a separate head. Seems like a great investment and the tripod seems to be much better than the previous one. After a year or two they realize that their last purchase was not that good, because the tripod is too heavy and hard to use, especially for traveling. They realize that they should have listened to the pros in the beginning and bought a good tripod system. Does this sound familiar? It certainly does for me, because I went through a similar experience and wasted too much effort and money.

Other photographers might have a different story, where they purchased an inexpensive tripod they like in the beginning and they are still happily using it today. All it says about them, is that they are not using their tripods as much and what they have is good enough for occasional use. Anybody who heavily relies on a tripod (especially landscape and architectural photographers) ends up buying two to three different tripods to eventually end up with the best.




It seems that it is hard to avoid purchasing multiple tripods, because it is often impossible to justify the cost of a good system to someone who does not heavily use a tripod. If someone told me that I would eventually spend more than $500 on a tripod system when I just got into photography, I would have never believed them – that’s too much money to spend on a darn tripod! But it all turned out to be true, because I actually ended up spending a lot more than $500 overtime, and I wish I could go back in time and buy the right stuff from the very beginning.

If I recommend someone who has just bought their first DSLR to buy the best tripod system that costs between $800 and $1,200, I will almost certainly get a “you are crazy” look, no matter how well I explain my story. Therefore, here is what I would recommend:

    If you currently do not have a tripod and you want to buy one, get the cheapest aluminum tripod system with an integrated head for less than $150 total. Why do I recommend the cheapest tripod? Because you first need to understand how much you will be using it. Six months down the road you might end up doing other type of photography that does not require a tripod or you might find yourself on a path of becoming a good landscape or macro photographer. A cheap tripod will give you enough information to understand the real role of a tripod in your photography.


    If you already have a cheap tripod and you want to get something better, save yourself a lot of money and frustration and get the best tripod with an arca-swiss quick release system – skip the middle. Some people buy cheaper legs and heads and either find them too heavy or unstable. One common problem with other quick-release systems, is the fact that cheaper plates do not grip well on cameras and start wiggling and rotating relative to the base, making it a nightmare for panoramic photography.

Extreme Cheapo Tripod Test (feat. Gitzo tripod)



Instances where a tripod is essential include:

  1. Low light, night sky, star trails and Aurora photography
  2. Using heavy camera gear, medium and large format cameras for landscapes
  3. Using large heavy telephoto lenses (e.g. 300mm F2.8 or larger lenses)
  4. Close-up photography with a macro lens without a flash
  5. Taking self portraits using a self timer
  6. For HDR imaging where you need to combine and overlay several images in register
  7. For focus stacking where you combine images that vary in focus
  8. For creating water motion blur effects
  9. For time lapse photography
  10. For creating landscapes having maximum depth of field and using apertures of F11 to F64
  11. For shooting HD video without constant up and down jerky movements
  12. For anyone that might have trouble holding their camera steady

What to look for when buying a tripod for nature photography

The requirements of a good tripod for nature photography are more stringent than buying a tripod for use in a studio. The tripod must be light in weight to be carried into the field, it must withstand a wide variety of environmental conditions and for macrophotography must be able to be positioned close to the ground. The tripod should also be quick to set up, easy to use and not alert your presence to wildlife (i.e. legs should be black, green or camo). The legs should be able to extend flat on the ground and each leg should be able to move independent of the other legs for work on uneven terrain. An important part of your tripod is the head used to attach and maneuver the camera (discussed later).





Also the legs should attach to the tripod using a strong simple connector with reinforcement posts for greater stability (e.g. Gitzo) no springs or gears. The leg locks should be quick to set up (twist type or clips) and should be usable when the tripod legs are immersed in water. The tripod should ideally come to your chin in height so it's comfortable to work with standing up. The legs should be lightweight, rigid but strong so they don't break if the tripod falls over or someone steps on it.

Have a nice shooting !
